Vertical Workshop Optical Comparator (VOC

Basic Info.

Model NO.	VOC-1005
Stage Travel Y Axis	50mm
Glass Table′s Size	175*100mm
Name	Vertical Profile Projector
Resolution	0.5 Micron
Metal Table′ Size	306*152mm
Accuracy	2.5+L/150
Transport Package	Standard Exporting Package
Specification	SGS
Trademark	Leader
Origin	Dongguan
HS Code	9031491000
Production Capacity	50, 000PCS/Year

Product Description

Vertical Workshop Optical Comparator (VOC-1005)

Video: http://leader-precision.en.made-in-china.com/custom/The-Video-of-Profile-Projector-Optical-Comparator-cQampFSPsnkb.html
Vertical Workshop Optical Comparator VOC-1005 is precise and excellent non-contact optical measuring device integrating with the technology of optic, mechanic, electricity and computer. This Measuring and Profile Projector is widely used at the fields of mechanism, meter, electronic, rubber industry, watch for quality control.
Vertical Workshop Optical Comparator VOC-1005 is very popular in the market, this Optical inspect device is a perfect metrology solution to the contour and surface measurement.
Vertical Workshop Optical Comparator VOC-1005 can inspect all kinds of surface and outline of complicated work-pieces, such as cam, screw thread, gear, milling cutter, tool, dies, press components and so on, This benchtop optical measurement device is an effective metrical and analytic system for education, research institute and lab.
Features:
1. Excellent optical measuring system
2. Magnification accuracy: 0.08% under contour illumination; 0.12% under surface illumination
3. Equipped with DC-3000 Metrology Counter for Geometry measurement.
4. Supplied with Foot-switch for quick measuring.
5. Erect image measuring for different requirements
6. High Precision measuring table with T-slot, easy to fix the work pieces
7. High resolution 0.5 micron linear scale
8. Customer can also choose optical Edge Detector system as option for auto measurement.
9. Customer can also choose Metrology software as option, the measurement data can be exported to Ms OFFICE
Profile Projector Warranty:
We supply 18 months Warranty time instead of 12 months

Technical Data:
Reverse	VOC-1505O				VOC-1005O
Erect	VOC1505				VOC1005
Metal table's size(mm)	340*152				306*152
Glass table's size(mm)	196*96				175*100
Stage Travel X-axis	150mm				100mm
Stage Travel Y-axis	50mm				50mm
Stage Travel Z-axis	90mm(for focus)				90mm(for focus)
Resolution	0.5µm				0.5µm
Measuring unit	Built-in linear scales				Built-in linear scales
Accuracy	≤(3+L/75)µm				≤(2.5+L/150)µm
Screen	Screen Diameter: ¢312mm with 4 film clips
	Screen material: fine ground glass
	Reference line: Staggered cross and crosshair
	Screen rotary range: 0°~360°
	Rotary angle resolution:1' or 0.01°
Digital Readout	DC-3000 Metrology Counter with RS-232C output Coordinate skew, mm/inch conversion, ABS/INC conversion, Zero setting, ½ calculation, 0 ° 90 ° 270 ° 360 ° conversion, linear compensation, RS-232 data output
Illumination	Contour illumination: 24V/150W halogen bulb Reflected illumination: 24V/150W halogen bulb Filter (option) for contour illumination
Power	AC110-120v, 200-240v, single phase 50/60Hz,Total power 400W
Cooling	Built-in cooling fans
G.W/N.W	165/110KG				160/105KG
Technical Data of Objective Lens:
Objective Lens	Magnification			10X	20X			50X	100X
	View field diameter			¢30	¢15			¢6.1	¢3
	Working Distance(mm)			77.7	44.3			38.4	25.3
	Max. Workpiece height			80mm	80mm			80mm	80mm
Standard Delivery:
Digital Readout DC-3000		VOC-10X Objective					Screen Clamp
Foot-Switch		Rotary table					Power cable
Optional Delivery:
2D Measuring Software			Optical Edge Detector			Overlay Charts (3 kinds)
VOC-20X Objective lens			VOC-50X Objective lens			VOC-100X Objective lens
Holder with Clamp			V Block with Clamp			SwivelCenterSupport
Mini-Printer			Calibration Scale			Calibration gauge
