Image Processing Large Toolmaker′s Microscope (JX14C)

Basic Info.

Model NO.	JX14C
Shape	Cylindrical Shaped Lens
Usage	Industry measurement
Principle	Optics
Accuracy	(2+L/50) micrometer
Gross magnification	10X, 30X, 50X
Objective magnification	1X, 3X, 5X
Resolution	0.001mm
Measurement Range (X*Y)mm	150mm*75mm
Transport Package	Veneer Case
Specification	ISO9001: 2000 CE Certificate
Trademark	Sinpo
Origin	Guizhou, China
HS Code	9011800090
Production Capacity	1000 Units/Year

Product Description

JX14C Image processing Large Toolmaker's microscope

Feature
The photoelectrical technique is adopted, with a precision grating rule as a measuring element for X- and Y-axle and a numbering; With readings direct-viewing and testing convenient.
Adopt Digital image technology, automatic recognition of contour, eliminate personal error, enhance operation efficiency.
Equipped with powerful image processing software, can accomplish complicated measuring task, and realize communication with CAD.
With multiple eyepieces and objectives, the main microscope has a large scope of view field with clear image formation.
The main microscope can oscillate left and right, suitable for the measurement for spiral parts.
LED-illuminating lighting is adopted for transmission and reflecting illumination, with low heating power and long life.
High-speed and micro-motion devices are adopted, which can be switched over quickly.
The tailstock rack is installed to measure the axel-type parts.
Multiple accessories such as V type support, optical detector are provided, with extensive uses.
Technical Parameter
Worktable
Measuring range of coordinate
X-coordinate: 150mm Y-coordinate: 75mm
Measuring resolution ratio: X- and Y- coordinate: 0.001mm
Accuracy of the instrument: X- and Y- coordinate: (2+L/50)μ M, of which, L=measured length in mm
Diameter of the circular worktable: φ 190mm (glass) φ 280mm (Metal)
Angular calibrated range of the circular worktable: 0° ~360°
Measured angle resolution ration of the circular worktable: 3
Microscope upright column
Sloping scope: ± 12°
Calibrated value of the slope angle: 30
Optical detector:
Minimum detective hole diameter of the optical detector: φ 5mm
Maximum detective depth of optical detector: 15mm
Measuring Force: 0.1N
Tailstock rack:
Maximum clamping diameter: φ 70mm
Maximum clamping length: 190mm
Objective
Objective magnification Total magnification Object working distance (mm) Image magnification
1× 10× 82 40×
3× 10× 70 120×
5× 10× 49 200×
Image range on screen (mm)
1/25.2× 4.1 1/34.1× 3.1
1/21.7× 1.4 1/31.4× 1.0
1/21.0× 0.8 1/30.8× 0.6
Maximum load: 20kg
Overall size of instrument: 720× 460× 600
Weight of instrument: 100kg

Model		JX14C
X-coordinate(mm)		150mm
Y-coordinate(mm)		75mm
Resolution ration (mm)		X and Y coordinate:0.001mm
Accuracy		(2+L/50)μm
Angular calibrated range of the circular worktable		0°~360°
Angle resolution ratio of circular worktable		3′
Diameter of circular worktable		φ190mm (glass) φ280mm(metal)
Microscope upright column	Sloping scope	±12°
	Calibrated value of slope angle	30′
Template eyepiece	Calibrated range
	Angular calibrated value
Tailstock rack	Max clamping diameter	φ70mm
	Max clamping length	190mm
Optical detector	Min detective hole diameter	φ5mm
	Max detective depth	15mm
Objective magnification		1X 3X 5X
Gross magnifying power		10X 10X 10X
Object working distance		82mm 70mm 49mm
Object visual field		40X 120X 200X
Overall sizes (mm)		720×460×600
Weight		100kg
Max load		20kg
Measuring Force		0.1N
Image range on screen		1/2″≈5.2×4.1 1/2″≈1.7×1.4 1/2″≈1.0×0.8
		1/3″≈4.1×3.1 1/3″≈1.4×1.0 1/3″≈0.8×0.6
